Know every cell of your battery.
OpenBMS protects, balances and measures 2 to 7 cell Li-ion and Li-Po packs, and learns your battery so the charge level you see is the charge you have. Hardware, firmware and software, all open.
Features
- Li-ion / Li-Po batteries
- 2-7 cells in series
- Cell voltage and pack current measurement - 24-bit ADC
- Firmware protections
- Overvoltage and undervoltage
- Overcurrent - charge and discharge
- Overtemperature and undertemperature - separate limits while charging
- Hardware protections - work without firmware
- Overcurrent and short circuit
- Overvoltage and undervoltage
- Fuse - backup overcurrent protection
- TVS diodes - voltage spike protection
- On-board battery learning - HPPC test figures out the model of your battery
- State of Charge (SoC) - per cell, 2RC model with extended Kalman filter
- State of Health (SoH) - capacity update over time
- Temperature compensation - battery model adjusts for cold and hot cells
- SoC based passive cell balancing
- Host communication - UART, I2C and CAN
- Settings and learned battery model saved in EEPROM
Inside the board
OpenBMS in numbers
- Cells - 2 to 7 in series
- Pack voltage - 5 to 30.1 V (2.5 to 4.3 V per cell)
- Max continuous current - 19 A
- Short circuit trip - 19.5 A, hardware
- Fuse protection - 25 A
- Measurement - 24-bit ADC
- Voltage accuracy - ±1 % (uncalibrated)
- Current accuracy - ±1 % (uncalibrated)
- Balancing current - up to 80 mA per cell
- Connector to connector resistance - 9.3 mΩ
- Consumption, running - 7 mA
- Consumption, shutdown - below 2 µA
- Operating temperature - -20 °C to +85 °C
- SoC error in tests - average -0.1 % to +0.5 % (min -1.8 %, max +2.8 %)
- Dimensions - 68.4 × 52.4 mm
- Weight - 26 g
- Open source - 100 %
- Rev B hardware released
- MIT / CERN-OHL-S v2
- Funded by NLnet
Connect, learn, run
OpenBMS sits between your battery and your system, and talks to your host or PC.
- Step 1
Connect
Put OpenBMS between your battery and your load or charger.
- Step 2
Learn
Run the on-board learning test once. OpenBMS builds a model of every cell.
- Step 3
Run
Get accurate state of charge, protection and balancing for the life of the pack.
The OpenBatt family
Everything you need to build, test and run a managed battery pack.
OpenBMS (Hardware)
The battery management system: hardware and firmware for 2 to 7 cell packs.
Learn more
OpenBMS Test Bench (Hardware)
A 600 W resistive load for charge and discharge testing.
Learn more
OpenBMS Studio (Software)
PC app to configure, monitor, visualise and update OpenBMS.
Learn moreBuilt for real projects
Drones & RC
Know exactly how much flight time is left.
E-boards & e-bikes
Safe high-current packs with real range.
Solar storage
Long-life packs that track their own health.
DIY & robotics
A BMS you can read, change and integrate.
Where we are
The hardware and firmware are done. OpenBMS Studio and testing are in active development.
| Module | Status |
|---|---|
| OpenBMS Schematics & PCB Layout | Done |
| OpenBMS Test Bench Schematic & PCB Layout | Done |
| Battery Algorithms & Simulations | Done |
| Revision B (Hardware improvements) | Done |
| OpenBMS Firmware (STM32) | Done |
| Desktop App (OpenBMS Studio) | In progress |
| BMS, Test Bench & Battery Tests | In progress |
| Documentation & Final Release | In progress |
We are a few engineers who love making battery projects and can’t believe how complicated, expensive, and proprietary they become. It doesn’t have to be rocket science, right?
What Is This About?
Open source embedded electronics projects for rechargeable batteries. Schematics, firmware, docs — all free, all open, all yours. Use it, break it, improve it, ship it in your project. We genuinely don’t mind.
Join Us
Found a bug? Great, you’re now a contributor. Have an idea? Even better. Just want to say hi? We like that too.
The battery is open. Come help us charge it! ⚡
This project is funded through NGI0 Commons Fund, a fund established by NLnet with financial support from the European Commission’s Next Generation Internet program.
We are very grateful to the NLnet team for their support, and we encourage you to apply and get funded to build your own project! 🚀 Learn more at the NLnet project page.
Want OpenBMS in your project?
OpenBMS is not for sale yet, but everything is open on GitHub. Build your own, or write to us about your project.
